Features

·Installation: Ceiling
·Material: AL1070
·Coating: Black
·Dimming method: Non/DALI-2/CASAMBI
·Input voltage: DC24-48V&DC48V
·SDCM: <3 Step (ANSI)
·UGR: <10
·CRI: 90
·CCT: 2700K/3000K/4000K/3000K-3800K-5000K optional
·Beam angle: 15°,24°,28°,36°,50°
·Application: Indoor
·IP grade: IP20
·Warranty: 5 years
·Certification: CE、UKCA、ROHS、Reach

BASIC CONFIGURATION

HTM53SL-42_Module(DC24-48V&DC48V) No Including power supply no application accessories Required for use with Base, Base needs to be ordered separately

Dimension

HTM53SL-42

$
**
/set
Login to view price

Flexible Options

Reset selected

Length:
φ42mm Spotlight
Typ.power:
6W
Color:
Black
CRI:
>90
Inner Ring Color:
Black
Version
  • Normal

  • 3 CCT tunable(Dial switch)

Beam Angle
  • 15°

  • 24°

  • 28°

  • 36°

  • 50°

Dimming Method
  • Non-Dimming

  • DALI Dimming

CCT
  • 2700K

  • 3000K

  • 4000K

  • 3000K-3800K-5000K

Input Voltage
  • DC48V

  • DC24-48V

Optical Accessory
  • No Honeycomb

  • Honeycomb

Label Type
  • COLORS

  • Customized Label

Ordering Code :

$ **/set

Common Accessories

Accessories Type
  • Power Supply
  • Controller
  • Other
Specifications
