Infinite Wave Recessed

If you don't need complex customization, Infinite Lights provides you with a wide range of ready-made shapes to choose from. You only need to confirm the basic specifications and parameters to obtain the product you need.

Feature

  • Aesthetics Without Seams
  • Mainstream Size Options
  • Powerful Performance
  • Multiple Types Of Installation

Certification

General Info

Application
Indoor
Mounting Type
Recessed
Light Direction
Direct
Dimension
D450mm,D600mm,D800mm,D1000mm,D1200mm,D1500mm,D2000mm,D3000mm
Lamp Body Material
AL6063-T5
Finish Colors
Black,Silver,White
Diffuser Type
Diffuser
Cover Material
PC
Diffuser Transmittance
>80%
Fire-Resistance Rating
UL94-V2
IP Rating
IP20
Operating Temperature
-15~35℃
Storage Temperature
0℃-40℃
Warranty
5 years
Certifications
CB,CE,ENEC,LM80,Reach,RoHS,UKCA

Electrical Info

Input Voltage
AC200-240V
Driver Brand
LiFud
Electrical Insulation Class
Class I
Dimming
1-10V,DALI-2,Non-Dimming

Optical Info

Version
High efficiency,Regular
LED Type
SMD2835
LED Brand
Lumileds,QZOPTO
CRI
Ra80+,Ra90+
CCT
2700K,3000K,3500K,4000K,5000K,6500K
SDCM
≤3 Step (ANSI)
Beam Angle
100°
Luminous Efficacy
120 lm/W,120 lm/W max,135 lm/W
LED Voltage
DC36V
LED Lifetime
000H,>50,L90B10(Ta 25℃)

Download

Product Code

Dimension

Filter by Dimension

Finish Colors

Filter by Finish Colors

Version

Filter by Version

CRI

Filter by CRI

CCT

Filter by CCT

Luminous Efficacy

3 matching product codes
W-CE7035D

W-CE7035D

ORDER NOW
NameVersionDimensionSystem PowerCRICCTFinish ColorsBeam AngleSystem OutputLuminous EfficacyInput VoltageDownload
-RegularD600mm27WRa80+2700KWhite100°2525 lm94 lm/WAC200-240V
-RegularD600mm27WRa80+3000KWhite100°2673 lm99 lm/WAC200-240V
-RegularD600mm27WRa80+3500KWhite100°2881 lm107 lm/WAC200-240V
-RegularD600mm27WRa80+4000KWhite100°2970 lm110 lm/WAC200-240V
-RegularD600mm27WRa80+5000KWhite100°2970 lm110 lm/WAC200-240V
-RegularD600mm27WRa80+6500KWhite100°2970 lm110 lm/WAC200-240V
-RegularD600mm27WRa90+2700KWhite100°2168 lm80 lm/WAC200-240V
-RegularD600mm27WRa90+3000KWhite100°2317 lm86 lm/WAC200-240V
-RegularD600mm27WRa90+3500KWhite100°2465 lm91 lm/WAC200-240V
-RegularD600mm27WRa90+4000KWhite100°2554 lm95 lm/WAC200-240V
  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 14
W-CE5035D

W-CE5035D

ORDER NOW
NameVersionDimensionSystem PowerCRICCTFinish ColorsBeam AngleSystem OutputLuminous EfficacyInput VoltageDownload
-RegularD450mm15WRa80+2700KWhite100°1275 lm85 lm/WAC200-240V
-RegularD450mm15WRa80+3000KWhite100°1350 lm90 lm/WAC200-240V
-RegularD450mm15WRa80+3500KWhite100°1455 lm97 lm/WAC200-240V
-RegularD450mm15WRa80+4000KWhite100°1500 lm100 lm/WAC200-240V
-RegularD450mm15WRa80+5000KWhite100°1500 lm100 lm/WAC200-240V
-RegularD450mm15WRa80+6500KWhite100°1500 lm100 lm/WAC200-240V
-RegularD450mm15WRa90+2700KWhite100°1095 lm73 lm/WAC200-240V
-RegularD450mm15WRa90+3000KWhite100°1170 lm78 lm/WAC200-240V
-RegularD450mm15WRa90+3500KWhite100°1245 lm83 lm/WAC200-240V
-RegularD450mm15WRa90+4000KWhite100°1290 lm86 lm/WAC200-240V
  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 16
W-CE3535D

W-CE3535D

ORDER NOW
NameVersionDimensionSystem PowerCRICCTFinish ColorsBeam AngleSystem OutputLuminous EfficacyInput VoltageDownload
-RegularD450mm13WRa80+2700KWhite100°1105 lm85 lm/WAC200-240V
-RegularD450mm13WRa80+3000KWhite100°1170 lm90 lm/WAC200-240V
-RegularD450mm13WRa80+3500KWhite100°1261 lm97 lm/WAC200-240V
-RegularD450mm13WRa80+4000KWhite100°1300 lm100 lm/WAC200-240V
-RegularD450mm13WRa80+5000KWhite100°1300 lm100 lm/WAC200-240V
-RegularD450mm13WRa80+6500KWhite100°1300 lm100 lm/WAC200-240V
-RegularD450mm13WRa90+2700KWhite100°949 lm73 lm/WAC200-240V
-RegularD450mm13WRa90+3000KWhite100°1014 lm78 lm/WAC200-240V
-RegularD450mm13WRa90+3500KWhite100°1079 lm83 lm/WAC200-240V
-RegularD450mm13WRa90+4000KWhite100°1118 lm86 lm/WAC200-240V
  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 16
