• Max.110lm/w, Free Cutting
  • 7-year warranty, high reliability
  • Max.20m@48V
  • For building facades and outdoor landscapes

Feature

  • Cut-to-Size · Accurate Fit for Easy Installation
  • Ultra High Light Efficiency & More Energy Saving
  • UV and Yellowing Resistance
  • No Worry About Siphonage and Water Seepage
  • Dual-Layer Protective Terminal
  • Anti-Breakage PCB Are More Durable
  • Worry Free About Quality
  • Withstands Installation Stresses
  • Upgraded Light-Emitting Structure, Even Color Without Dark Area On Surface
  • Precision-Controlled Color Temperature After Silicone Coated

Certification

General Info

Application
outdoor
IK Rating
IK08
IP Rating
IP67
Operating Temperature
-20~50℃
Storage Temperature
0℃~60℃
Warranty
7years
Certifications
UKCA、CE、UL、CB、RoHS、REACH
Bend Direction
Top-Bend

Electrical Info

Max-Run(Single-End Feed)
10m,20m
Input Voltage
DC24V,DC48V
Electrical Insulation Class
Class III
Typ.Power
10W/M

Optical Info

LED Type
2835
CRI
Ra90+
CCT
2200K,2700K,3000K,4000K
Cutting Unit
6.25mm,12.5mm
LED QTY
160LEDs/m

Download

Product Code

CCT

Filter by CCT

Input Voltage

Filter by Input Voltage
2 matching product codes
AHT1616-White light-48V

AHT1616-White light-48V

ORDER NOW
NameInput VoltageTyp.PowerCRICCTSystem OutputLuminous EfficacyWarrantyDownload
-DC48V10 W/m[3.05 W/ft]Ra90+2200K800 lm/m[244 lm/ft]80 lm/W7years
-DC48V10 W/m[3.05 W/ft]Ra90+2700K930 lm/m[284 lm/ft]93 lm/W7years
-DC48V10 W/m[3.05 W/ft]Ra90+3000K990 lm/m[302 lm/ft]99 lm/W7years
-DC48V10 W/m[3.05 W/ft]Ra90+4000K960 lm/m[293 lm/ft]96 lm/W7years
AHT1616-White light-24V

AHT1616-White light-24V

ORDER NOW
NameInput VoltageTyp.PowerCRICCTSystem OutputLuminous EfficacyWarrantyDownload
-DC24V10 W/m[3.05 W/ft]Ra90+2200K725 lm/m[221 lm/ft]73 lm/W7years
-DC24V10 W/m[3.05 W/ft]Ra90+2700K860 lm/m[262 lm/ft]86 lm/W7years
-DC24V10 W/m[3.05 W/ft]Ra90+3000K910 lm/m[277 lm/ft]91 lm/W7years
-DC24V10 W/m[3.05 W/ft]Ra90+4000K940 lm/m[287 lm/ft]94 lm/W7years
