Underwater applications, 3m deep;
IP68 IP69K IK10;
5-year warranty;
T-type TPU;
For Swimming Pool & Sea Water & Onsen.
Feature
- IP68 & IP69K
- 5-Years Warranty For Underwater Applications
- PC Profile + Waterproof Junction Box Installation Solution For Underwater Application
- Anti-Breakage PCB Are More Durable
- Anti-Dead Chips Without Dark Area
- Withstands Installation Stresses
- Rich Range Of Light Colors
Certification
General Info
- Application
- outdoor
- IK Rating
- IK08
- IP Rating
- IP68
- Operating Temperature
- -20~50℃
- Storage Temperature
- 0℃～60℃
- Warranty
- 5years
- Certifications
- UKCA、CE、UL、CB、RoHS、REACH
- Bend Direction
- Top-Bend
Electrical Info
- Max-Run(Single-End Feed)
- 5m
- Input Voltage
- DC24V
- Electrical Insulation Class
- Class III
- Typ.Power
- 10W/M
Optical Info
- LED Type
- COF
- CRI
- Ra90+
- CCT
- 2700K,3000K,4000K,6500K
- Cutting Unit
- 50mm
- LED QTY
- 320LEDs/m
Download
Product Code
CCT
Filter by CCT
| Name | Input Voltage | Typ.Power | CRI | CCT | System Output | Luminous Efficacy | Warranty | Download |
|---|---|---|---|---|---|---|---|---|
| - | DC24V | 10 W/m[3.05 W/ft] | Ra90+ | 2700K | 520 lm/m[159 lm/ft] | 52 lm/W | 5years | |
| - | DC24V | 10 W/m[3.05 W/ft] | Ra90+ | 3000K | 560 lm/m[171 lm/ft] | 56 lm/W | 5years | |
| - | DC24V | 10 W/m[3.05 W/ft] | Ra90+ | 4000K | 630 lm/m[192 lm/ft] | 63 lm/W | 5years | |
| - | DC24V | 10 W/m[3.05 W/ft] | Ra90+ | 6500K | 600 lm/m[183 lm/ft] | 60 lm/W | 5years |
