Features

· Material: AL6063-T5, spraying surface
· Coating: Black (RAL9005)
·Length: 300mm/600mm/900mm optional
· IP grade: IP20
· CCT: 2700/3000/3500/4000K optional
· CRI: 90
· SDCM: <5 Step (ANSI)
· Light efficiency: 70 lm/W
· Input voltage: DC48V
· Lighting direction: downward
· Dimming method: Non / DALI-2 / Tuya Bluetooth / CASAMBI
· Application: Indoor
· Certification: CE、UKCA、ROHS、Reach
· Warranty: 3 years

BASIC CONFIGURATION

M20FD_Module(DC48V) Required track installation Including electrical conector

M20FD(E)(DC48V)

$
**
/set
Login to view price

Flexible Options

Reset selected

Diffuser Nature
  • Diffuser

Length
  • 300mm

  • 600mm

  • 900mm

Typ.power
  • 7W

  • 20W

  • 14W

Color
  • Black

Dimming Method
  • Non-Dimming

  • DALI Dimming

  • Tuya-Bluetooth Mesh Dimming

CRI
  • >90

CCT
  • 2700K

  • 3000K

  • 4000K

Label Type
  • Customized Label

  • COLORS

Ordering Code :

$ **/set

Common Accessories

Accessories Type
  • Cover
  • End cap accessory
  • Standard Corner
  • Power feeder
  • Splicing accessory
  • Installation accessory
  • Track
  • Controller
