Features

· Material:AL1070,spraying surface
· Coating: Black (RAL9005)/White (RAL9003)
· IP grade: IP20
· CCT: 2700K,3000K,4000K,3000K-4000K-5000K optional
· CRI: 90
· SDCM(Light source):≤3 Step(ANSI)
· Beam angle: 12°,15°,20°,24°,30°,36°,45°,50° optional
· Light efficiency: 93LM/W optional
· Input voltage: DC24-48V,DC48V
· Lighting direction: Downward
· Dimming method: Non,DALI-2,Tuya Bluetooth,CASAMBI
· Application: Indoor
· Certification: CE,UKCA,ROHS,Reach
· Warranty: 5 years

BASIC CONFIGURATION

MT20S-62_Module Required track installation Including electrical conector Only some tracks of listed brands are compatible：Powergear, Stucchi

Dimension

MT20S-62

In-stock

Smart Picks

Reset selected

Version

Normal
3 CCT tunable(Dial switch)

Beam Angle

12°
15°
20°
24°
30°
36°
45°
50°

Color

Black
White

Dimming Method

Non-Dimming
DALI Dimming
Tuya-Bluetooth Mesh Dimming
External Dimming

CCT

2700K
3000K
3500K
4000K
3000K-4000K-5000K

Input Voltage

DC48V
DC24-48V

Optical Accessory

No Honeycomb
Honeycomb

Fixed Options

Length:

φ62mm Spotlight

Typ.power:

15W

CRI:

>90

Inner Ring Color:

Black

User Manual:

Label Type:

Customized Label

Ordering Code :

$ **/set

Common Accessories

Accessories Type

Track
End cap accessory
Power Supply
Splicing accessory
Installation accessory
Standard Corner
Controller

Specifications
