BASIC CONFIGURATION

MT20SZ-65_Module
Required track installation
Including electrical conector
Only some tracks of listed brands are compatible:Powergear, Stucchi

Features

· Material:AL1070,spraying surface
· Coating: Black (RAL9005)/White (RAL9003)
· IP grade: IP20
· CCT: 2700K,3000K,4000K optional
· CRI: 90
· SDCM(Light source):≤3 Step(ANSI)
· Beam angle: 15°-45° adjustable
· Light efficiency: 78LM/W optional
· Input voltage: DC24-48V
· Lighting direction: Downward
· Dimming method: Non,DALI-2,Tuya Bluetooth,CASAMBI
· Application: Indoor
· Certification: CE,UKCA,ROHS,Reach
· Warranty: 5 years

MT20SZ-65

Reset selected

Length
  • φ65mm Zoom Spotlight

Typ.power
  • 12W

Beam Angle
  • 15°-45° Angle Adjustable

Color
  • White

  • Black

Dimming Method
  • Non-Dimming

  • DALI Dimming

  • Tuya-Bluetooth Mesh Dimming

CRI
  • >90

CCT
  • 2700K

  • 3000K

  • 4000K

Inner Ring Color
  • Black

Input Voltage
  • DC24-48V

User Manual
  • EN

Label Type
  • COLORS

  • Customized Label

Ordering Code:

TLS-MT20SZ65-1290B1B

Qty

$ ** /SET

Ordering Code:

TLS-MT20SZ65-1290B1B
