Led_Qty：168LEDs/m
Typ.Power：7.2W/M
Min Cut：14led/83.3mm
Luminous flux:480LM/m@4000K
Bend radius：≥60mm
IP:IP67
Warranty：5years indoor,Working life ≥60000 hours;3years semi-outdoor,Working life ≥36000 hours
Product Certification：UKCA、CE、UL、ROHS、REACH
Operating/storage temperature:Ta:-25~55℃ / 0℃～60℃
NM3D1515-White light-48V
$
**
/m
Login to view price
Flexible Options
Reset selected
CCT
1800K
2200K
2700K
3000K
4000K
CRI
>90
Typ.power
7.2W/M
others
Silk Printing
COLORS
Neutral
Customize
others
Strip Length
5M
10M
20M
Customized Length
Entry Cable
S(One-end top)
D(Dual-end top)
S(One-end bottom)
D(Dual-end bottom)
S(One-end side left)
D(Dual-end side left)
Wire Type
Silicone
PVC
Wire Length
50CM
200CM
Length customization
Label Type
COLORS
Engineering package
Customized Label
Voltage
48V
IP
ENP(IP67 molded end cap without dark area)
Gluing end cap(IP65)
ESD
ESD
Delivery Date
Ordering Code :
NM3D1515-948-ESD
$ **/m
When the customized length is more than 10M, you need to choose the double-end out of the line, more than 10M length is the length that can be supported by the packaging shipment, not the length of the product for direct use.
Product model:AS-NM3D1515GH0-EC, NM3D1515 Top wire outlet metal plug set
Outlet direction: top
IP:IP65
Included: Silicone plug and end cap
Applicable product model：NM3D1515\NMT1515
Product model:AS-NM3D1515M-1000，NM3D1515 Stylable installation Groove
Installation method：Stylable Installation
Coating：silvery
Size：L997*W17.4*H18.8
Quantity: 1PCS/ set
Recommended dosage:1PCS/M
Applicable product model：NM3D1515
Not to be used with the lighted side down
Product model:AS-NM3D1515M-500，NM3D1515 Stylable installation Groove
Installation method：Stylable Installation
Coating：white
Size：L500*W16.4*H16
Quantity: 2PCS/ set
Recommended dosage:2PCS/M
Applicable product model：NM3D1515/NMT1515
Not to be used with the lighted side down
$ ** /SET
Login to view price
1
2
3
Request A Quote
