Features

·Material:AL6063-T5,spraying surface
·Coating:Black(RAL9005)、White(RAL9003)
·Lighting direction: downward
·Light efficiency:75LM/W
·UGR: ≤ 19 (X=4H, Y=8H)
·Dimming method:Non/ DALI-2+PUSH/ 1-10V optional
·Length:600mm/1200mm/1500mm/1800mm/2400mm optional (other length on request)
·Color tolerance:SDCM≤3(ANSI)
·CRI:80/90
·CCT:2700/3000/3500/4000/5000/6500/3000-6500K optional
·Input voltage:AC200-240V
·Application: Indoor
·Installation:Pendant、Ceiling
·IP grade:IP20
·Certification:CE、UKCA、ROHS、Reach
·Warranty:5 years

BASIC CONFIGURATION

S40HP_Module(AC220V) Including power supply no application accessories

S40HP

$
**
/set
Login to view price

Flexible Options

Reset selected

Version
  • Normal

  • 3 CCT tunable(Dial switch)

Diffuser Nature
  • Honeycomb

Length
  • 600mm

  • 1200mm

  • 1500mm

  • 1800mm

  • 2400mm

Typ.power
  • 68W

  • 51W

  • 46W

  • 34W

  • 17W

Carrier Style
  • No carrier

Color
  • Black

  • White

Dimming Method
  • Non-Dimming

  • 1-10V Dimming

  • DALI Dimming

CRI
  • >80

  • >90

CCT
  • 2700K

  • 3000K

  • 3500K

  • 4000K

  • 5000K

  • 6500K

  • 3000K-6500K

Light Source Type
  • Constant Current Rigid PCB

End Cap Style
  • Holeless end cap

Label Type
  • Customized Label

  • COLORS

Package
  • COLORS Individual

Ordering Code :

$ **/set

Common Accessories

Accessories Type
  • Profile
  • End cap accessory
  • Splicing accessory
  • Installation accessory
  • Power feeder
  • Standard Corner
