Features

·Material:AL6063-T5，spraying surface
·Coating:Black(RAL9005)、White(RAL9003)
·Lighting direction: downward
·Light efficiency:65LM/W
·UGR: ≤ 19 (X=4H, Y=8H)
·Dimming method:Non/ DALI-2+PUSH/ 1-10V optional
·Length:600mm/1200mm/2400mm optional (other length on request)
·Color tolerance:SDCM≤3(ANSI)
·CRI:80/90
·CCT:2700/3000/3500/4000/5000/6500/3000-6500 optional
·Input voltage:AC200-240V
·Application: Indoor
·Installation:Pendant、Ceiling、Trimless recessed
·IP grade:IP20
·Certification:CE、CB、UKCA、SAA、ROHS、Reach
·Warranty:5 years

S60BD

Name: S60BD
Brand: COLORS Lighting

/set

Flexible Options

Smart Picks

Reset selected

Version

Normal
3 CCT tunable(Dial switch)

Diffuser Nature

Louver

Length

600mm
1200mm
2400mm

Typ.power

Carrier Style

No carrier

Color

Black
White

Dimming Method

Non-Dimming
1-10V Dimming
DALI Dimming

CRI

CCT

2700K
3000K
3500K
4000K
5000K
6500K
3000K-6500K

Light Source Type

Constant Current Rigid PCB

End Cap Style

Holeless end cap

Label Type

Customized Label
COLORS

Package

COLORS Individual

Delivery Date

Ordering Code :

TLS-S60BDXS-T-D

$ **/set

Common Accessories

Accessories Type

Installation accessory
Profile
End cap accessory
Cover
Power feeder
Standard Corner
Splicing accessory

CL-06

Applicable product model:BS5470/LS5470(F)/LS60FD/LS60FP/LS60G/LS60BD/LS60HP/LS60LA/LS60LS/S60 Installation method: ceiling Material process: Iron zinc alloy/electroplating Size: 90.5*54*5.9mm Quantity: 2PCS/ set

$ ** /SET

CM-11

Applicable product model: S60 Material process: PVC Size: 1000*φ6mm Wire diameter:18AWG Quantity: 1PCS/ set Others:Module connection cable, length is 1m,3 pin non-dimming version，for the first module power feeding/ inter-modules power feeding

$ ** /SET

CM-12

Applicable product model: S60 Material process: PVC Size: 1000*φ6.5mm Wire diameter:18AWG Quantity: 1PCS/ set Others:Module connection cable, length is 1m，5 pin dimming version，for the first module power feeding/ inter-modules power feeding

$ ** /SET

CM-13

Applicable product model: S60 Material process: PVC Size: 2000*φ6mm Wire diameter:18AWG Quantity: 1PCS/ set Others:Module connection cable, length is 2m，3 pin non-dimming version，for the first module power feeding/ inter-modules power feeding

$ ** /SET

CM-14

Applicable product model: S60 Material process: PVC Size: 2000*φ6.5mm Wire diameter:18AWG Quantity: 1PCS/ set Others:Module connection cable, length is 2m，5 pin dimming version，for the first module power feeding/ inter-modules power feeding

$ ** /SET
