Features

·Material:AL6063-T5,spraying surface
·Coating:White(RAL9003) optional
·Lighting direction: downward
·Light efficiency:110LM/W
·Spotlight angle:28°/36°/45°/55°/35°x65° optional
·UGR: ≤ 13(X=4H, Y=8H)
·Opening size:φ98mm
·Dimming method:Non/ DALI/ 0-10V optional
·Color tolerance:SDCM≤5(ANSI)
·CRI:90
·CCT:2700/3000/4000/3000-5000K optional
·Input voltage:AC220-240V
·Application: Indoor
·Power installation:External
·Installation:Recessed
·IP grade:IP20
·Certification:CE、UKCA、ROHS、Reach
·Warranty:5 years

BASIC CONFIGURATION

SE98L luminaire Power supply optional no application accessories

SE98L

In-stock

Reset selected

Version
  • Normal

  • 3 CCT tunable(Dial switch)

Beam Angle
  • 28°

  • 36°

  • 45°

  • 55°

  • 35°x65°

Dimming Method
  • No Power

  • Non-Dimming

  • 0-10V Dimming

  • DALI Dimming

CCT
  • 2700K

  • 3000K

  • 4000K

  • 3000K-5000K

IP Grade
  • IP20

  • IP44

Entry Cable
  • With junction box

  • With cable of drive input

User Manual
  • EN

  • CN

Label Type
  • Customized Label

  • COLORS

Fixed Options
Length:
φ98mm Lens Spotlight
Typ.power:
15W
Color:
White
CRI:
>90
Ordering Code :

$ **/set
