Features

·Material:ADC12,spraying surface
·Driver Installation: Remote
·Lighting direction: downward
·Beamangle:10°/15°/24°/38°/50° optional
·UGR(X=4H, Y=8H): ≤6(10°/15°/24°),≤16(38°/50°)
·Opening size:φ75mm
·Dimming method:Non/1-10V/DALI optional
·SDCM(Light source): <3 Step(ANSI)
·CRI:90
·CCT:2700/3000/3500/4000K optional
·Input voltage:AC220-240V
·Application: Indoor
·Installation:Recessed
·IP grade:IP20
·Certification:CE、ROHS、Reach
·Warranty:5 years

BASIC CONFIGURATION

KE75L2 luminaire Power supply optional no application accessories Note: If the "Honeycomb" is selected, it will be installed on the spotlight by default,and the parameters will change as follows. (1)Spotlights with beam angles of "10°"，"15°" and "24°":the light efficiency will be reduced by 30%, the beam Angle will be reduced by 12%, the anti-glare effect will be better, and the UGR will be reduced by 40%. (2)Spotlights with beam angles of "38°" and "50°":the light efficiency will be reduced by 50%, the beam Angle will be reduced by 25%, the anti-glare effect will be better, and the UGR will be reduced by 40%.

Dimension

KE75L2

Reset selected

$
**
/set
Login to view price
CRI:
>90
IP Grade:
IP20
Size:
φ75mm Spotlight
Typ.power
  • 8W
  • 17W
  • 15W
  • 12W
  • 11W
  • 10W
Beam Angle
  • 10°
  • 15°
  • 24°
  • 38°
  • 50°
Color
  • Black(Frame)
  • White(Frame)
Dimming Method
  • No Power
  • Non-Dimming
  • 1-10V Dimming
  • DALI Dimming
CCT
  • 2700K
  • 3000K
  • 3500K
  • 4000K
Reflector Type
  • Round
  • Pin hole
  • Oval
Reflector Color
  • Mirror

  • Matte White

  • Matte Black

  • Champagne Gold

  • Black chrome

Optical Accessory
  • Honeycomb

  • Linear Spread Filter
  • Diffusion Filter
  • Honeycomb + Linear Spread Filter
  • Honeycomb + Diffusion Filter
  • NO
Entry Cable
  • With junction box
  • With cable of drive input
User Manual
  • EN
  • CN
Label Type
  • Customized Label

  • COLORS

Ordering Code :
Delivery Date :    7-15 Days

$ **/set

>90,
IP20,
φ75mm Spotlight
Specifications
