Features

· Material:AL6063-T5,spraying surface
· Coating: Black (RAL9005)/White (RAL9003)
· Length: 600mm,900mm,1200mm optional
· IP grade: IP20
· CCT: 2700,3000,4000K,3000K-4000K-5000K optional
· CRI: 90
· SDCM(Light source):≤3 Step(ANSI)
· Light efficiency: 100 LM/W
· Input voltage: DC24-48V,DC48V
· Lighting direction: Downward
· Dimming method: Non,DALI-2,Tuya Bluetooth,CASAMBI
· Application: Indoor
· Certification: CE,UKCA,ROHS,Reach
· Warranty: 5 years

BASIC CONFIGURATION

MT20CD(A)_Module Required track installation Including electrical conector Only some tracks of listed brands are compatible:Powergear, Stucchi

MT20CD(A)

$
**
/set
Login to view price

Flexible Options

Reset selected

Diffuser Nature:
Corss-track round tube
Beam Angle:
200°x110°
CRI:
>90
Cover Color:
White
User Manual:
EN
Version
  • Normal

  • 3 CCT tunable(Dial switch)

Length
  • 600mm

  • 900mm

  • 1200mm

Typ.power
  • 12W

  • 18W

  • 24W

Color
  • Black

  • White

Dimming Method
  • Non-Dimming

  • DALI Dimming

  • Tuya-Bluetooth Mesh Dimming

  • External Dimming

CCT
  • 2700K

  • 3000K

  • 3500K

  • 4000K

  • 3000K-4000K-5000K

Input Voltage
  • DC48V

  • DC24-48V

Label Type
  • COLORS

  • Customized Label

Ordering Code :

$ **/set

Common Accessories

Accessories Type
  • Track
  • End cap accessory
  • Power Supply
  • Power feeder
  • Splicing accessory
  • Installation accessory
  • Standard Corner
  • Controller
Specifications
