MT20LS_Module
Required track installation
Including electrical conector
Only some tracks of listed brands are compatible：Powergear, Stucchi
- EN
BASIC CONFIGURATION
Features
· Material:AL6063-T5,spraying surface
· Coating: Black (RAL9005)/White (RAL9003)
· Length: 300mm,600mm,900mm optional
· IP grade: IP20
· CCT: 2700K,3000K,4000K optional
· CRI: 90
· SDCM(Light source):≤3 Step(ANSI)
· Light efficiency: 100 LM/W
· Input voltage: DC24-48V,DC48V
· Lighting direction: Downward
· Dimming method: Non,DALI-2,Tuya Bluetooth,CASAMBI
· Application: Indoor
· Certification: CE,UKCA,ROHS,Reach
· Warranty: 5 years
· Coating: Black (RAL9005)/White (RAL9003)
· Length: 300mm,600mm,900mm optional
· IP grade: IP20
· CCT: 2700K,3000K,4000K optional
· CRI: 90
· SDCM(Light source):≤3 Step(ANSI)
· Light efficiency: 100 LM/W
· Input voltage: DC24-48V,DC48V
· Lighting direction: Downward
· Dimming method: Non,DALI-2,Tuya Bluetooth,CASAMBI
· Application: Indoor
· Certification: CE,UKCA,ROHS,Reach
· Warranty: 5 years
MT20LS
Reset selected
Diffuser Nature
Double Asymmetric
Length
300mm
600mm
900mm
Typ.power
7W
14W
20W
Beam Angle
100°x90°x15°
Color
White
Black
Dimming Method
Non-Dimming
DALI Dimming
Tuya-Bluetooth Mesh Dimming
CRI
>90
CCT
2700K
3000K
4000K
Cover Color
White
Input Voltage
DC48V
DC24-48V
User Manual
EN
Label Type
COLORS
Customized Label
Qty
$ ** /SET
Ordering Code:
TLS-MT20LS90W1W
Common Accessories
Controller
Installation accessory
End cap accessory
Standard Corner
Power Supply
Splicing accessory
Track
Power feeder
