Features

·Material: ADC12,spraying surface
·Coating: Black/ White optional
·Lighting direction: downward
·Spotlight angle: 24°/36° optional
·UGR(X=4H,Y=8H): ≤3(24°), UGR≤10(36°)
·Opening size: φ75mm
·Dimming method: Non/ DALI/0-10V/ Triac/ No power optional
·Color tolerance: SDCM≤3
·CRI: >90
·CCT: 2700/3000/3500/4000K optional
·Input voltage: AC220-240V
·Application: Indoor
·Power installation: External
·Installation: Recessed
·IP grade: IP20
·Certification: CE、UKCA、ROHS、Reach
·Warranty: 5 years

BASIC CONFIGURATION

P3E75L2 luminaire Power supply optional no application accessories

Dimension

P3E75L2

In-stock

Reset selected

Typ.power
  • 12W

  • 9W

Beam Angle
  • 24°

  • 36°

Color
  • Black(Frame)

  • White(Frame)

Dimming Method
  • No Power

  • Non-Dimming

  • 0-10V Dimming

  • DALI Dimming

  • Triac Dimming

CCT
  • 2700K

  • 3000K

  • 3500K

  • 4000K

Reflector Color
  • Mirror

  • Matte White

  • Matte Black

  • Black chrome

Optical Accessory
  • Honeycomb

  • NO

Entry Cable
  • With cable of drive input

  • With junction box

User Manual
  • EN

  • CN

Label Type
  • COLORS

  • Customized Label

Fixed Options
Length:
Opening φ75mm
CRI:
>90
IP Grade:
IP20
Ordering Code :

$ **/set
