Led_Qty：120LEDs/m
Typ.Power：5.3W/M
Min Cut：12led/100mm
Luminous flux:190LM/m@4000K
Bend radius：＞30mm
IP:IP65
Warranty：5years indoor,Working life ≥60000 hours;3years semi-outdoor,Working life ≥36000 hours
Product Certification：UKCA、CE、UL、ROHS、REACH
Operating/storage temperature:Ta:-25~55℃ / 0℃～60℃
NMS0612-White light-48V
$
**
/m
Login to view price
Flexible Options
Reset selected
CCT
2300K
2700K
3000K
4000K
CRI
>90
Typ.power
5.3W/M
Silk Printing
COLORS
Neutral
Customize
others
Strip Length
5M
10M
30M
Customized Length
Entry Cable
S(One-end top)
D(Dual-end top)
S(One-end bottom)
D(Dual-end bottom)
S(One-end side right)
D(Dual-end side right)
Wire Type
PVC
Gray wire
Wire Length
50CM
200CM
Length customization
Label Type
COLORS
Customized Label
ESD
ESD
Voltage
48V
IP
Metal end cap(IP65)
Gluing end cap(IP65)
Engineering Package
Engineering package
Delivery Date
Ordering Code :
NMS0612-948C-ESD
$ **/m
When the customized length is more than 30M, you need to choose the double-end out of the line, more than 10M length is the length that can be supported by the packaging shipment, not the length of the product for direct use.
Product model:AS-NMS0612GD0-EC, NMS0612 Bottom wire outlet silicone plug set
Outlet direction: bottom
IP:IP65
Included: Silicone plug and end cap
Applicable product model：NMS0612\NJS0612\NJS0612T
$ ** /SET
Login to view price
1
2
3
4
Request A Quote
