The LINE LINK Quick Connect lighting system features an innovative quick-connect end cap design, making the structural and electrical connections between fixtures simple and efficient. With a simple plug-and-play mechanism, users can achieve instant structural and electrical connections in just one second. Combined with its modular design, this system allows customers to quickly create extended configurations, significantly reducing the additional costs
associated with custom lengths.
Feature
- Innovative Quick-Connect End Cap Design
- Ultra Long Application
- Ultra-Long Single-End Power in
- Extra-Long Flexible Diffuser & Prismatic
Certification
General Info
- Application
- Indoor
- Mounting Type
- Surface Mounted,Suspended
- Light Direction
- Direct
- Dimension
- 300mm,1200mm,1800mm,2400mm
- Lamp Body Material
- AL6063-T5
- Finish Colors
- Black,White
- Diffuser Type
- Diffuser,Prismatic
- Cover Material
- PC,PC+PET
- Diffuser Transmittance
- >80%
- Fire-Resistance Rating
- UL94-V2
- IP Rating
- IP20
- Operating Temperature
- -15℃~35℃
- Storage Temperature
- 0℃-40℃
- Warranty
- 5 years
- Certifications
- CB,CE,ENEC,LM80,Reach,RoHS,UKCA
Electrical Info
- Input Voltage
- AC220-240V
- Driver Brand
- LiFud
- Electrical Insulation Class
- Class I
- Dimming
- 1-10V,DALI-2,Non-Dimming
Optical Info
- Version
- High Efficiency,High Efficiency-DIP Dual-color,Regular,Regular-DIP Dual-color
- LED Type
- SMD2835
- LED Brand
- Lumileds,QZOPTO
- CRI
- Ra80+,Ra90+
- CCT
- 2700K,3000K,4000K,6500K
- SDCM
- ≤3 Step (ANSI)
- Beam Angle
- 90°,100°
- UGR(4H,8H)
- UGR<19
- Luminous Efficacy
- 120 lm/W max,125 lm/W max,135 lm/W max,140 lm/W max,150 lm/W max
- LED Voltage
- DC36V
- LED Lifetime
- 000H,>50,L90B10(Ta 25℃)
Download
Product Code
Dimension
Filter by Dimension
Finish Colors
Filter by Finish Colors
Version
Filter by Version
CRI
Filter by CRI
CCT
Filter by CCT
Beam Angle
Filter by Beam Angle
Luminous Efficacy
| Name | Version | Dimension | System Power | CRI | CCT | Finish Colors | Beam Angle | System Output | Luminous Efficacy | Input Voltage | Download |
|---|---|---|---|---|---|---|---|---|---|---|---|
| - | Regular-3 CCT Dial Switch | 1800mm | 45W | Ra80+ | 4200K | White | 100° | 4500 lm | 100 lm/W | AC220-240V | |
| - | Regular-3 CCT Dial Switch | 1800mm | 45W | Ra80+ | 4200K | Black | 100° | 4050 lm | 90 lm/W | AC220-240V | |
| - | Regular-3 CCT Dial Switch | 2400mm | 58W | Ra80+ | 4200K | White | 100° | 5800 lm | 100 lm/W | AC220-240V | |
| - | Regular-3 CCT Dial Switch | 2400mm | 58W | Ra80+ | 4200K | Black | 100° | 5220 lm | 90 lm/W | AC220-240V | |
| - | Regular-3 CCT Dial Switch | 1200mm | 29W | Ra90+ | 4200K | White | 100° | 2494 lm | 86 lm/W | AC220-240V | |
| - | Regular-3 CCT Dial Switch | 1200mm | 29W | Ra90+ | 4200K | Black | 100° | 2245 lm | 77 lm/W | AC220-240V | |
| - | Regular-3 CCT Dial Switch | 1800mm | 45W | Ra90+ | 4200K | White | 100° | 3870 lm | 86 lm/W | AC220-240V | |
| - | Regular-3 CCT Dial Switch | 1800mm | 45W | Ra90+ | 4200K | Black | 100° | 3483 lm | 77 lm/W | AC220-240V | |
| - | Regular-3 CCT Dial Switch | 2400mm | 58W | Ra90+ | 4200K | White | 100° | 4988 lm | 86 lm/W | AC220-240V | |
| - | Regular-3 CCT Dial Switch | 2400mm | 58W | Ra90+ | 4200K | Black | 100° | 4489 lm | 77 lm/W | AC220-240V |
- 1
- 2
- 3
- 4
- 5
- 6
- 19
| Name | Version | Dimension | System Power | CRI | CCT | Finish Colors | Beam Angle | System Output | Luminous Efficacy | Input Voltage | Download |
|---|---|---|---|---|---|---|---|---|---|---|---|
| - | Regular-3 CCT Dial Switch | 1200mm | 38W | Ra80+ | 4200K | White | 100° | 4180 lm | 110 lm/W | AC220-240V | |
| - | Regular-3 CCT Dial Switch | 1200mm | 38W | Ra80+ | 4200K | Black | 100° | 3762 lm | 99 lm/W | AC220-240V | |
| - | Regular-3 CCT Dial Switch | 1800mm | 58W | Ra80+ | 4200K | White | 100° | 6380 lm | 110 lm/W | AC220-240V | |
| - | Regular-3 CCT Dial Switch | 1800mm | 58W | Ra80+ | 4200K | Black | 100° | 5742 lm | 99 lm/W | AC220-240V | |
| - | Regular-3 CCT Dial Switch | 2400mm | 76W | Ra80+ | 4200K | White | 100° | 8360 lm | 110 lm/W | AC220-240V | |
| - | Regular-3 CCT Dial Switch | 2400mm | 76W | Ra80+ | 4200K | Black | 100° | 7524 lm | 99 lm/W | AC220-240V | |
| - | Regular-3 CCT Dial Switch | 1200mm | 38W | Ra90+ | 4200K | White | 100° | 3595 lm | 95 lm/W | AC220-240V | |
| - | Regular-3 CCT Dial Switch | 1200mm | 38W | Ra90+ | 4200K | Black | 100° | 3235 lm | 85 lm/W | AC220-240V | |
| - | Regular-3 CCT Dial Switch | 1800mm | 58W | Ra90+ | 4200K | White | 100° | 5487 lm | 95 lm/W | AC220-240V | |
| - | Regular-3 CCT Dial Switch | 1800mm | 58W | Ra90+ | 4200K | Black | 100° | 4938 lm | 85 lm/W | AC220-240V |
- 1
- 2
- 3
- 4
- 5
- 6
- 20
| Name | Version | Dimension | System Power | CRI | CCT | Finish Colors | Beam Angle | System Output | Luminous Efficacy | Input Voltage | Download |
|---|---|---|---|---|---|---|---|---|---|---|---|
| - | Regular | 1200mm | 47W | Ra80+ | 4000K | White | 100° | 5405 lm | 115 lm/W | AC220-240V | |
| - | Regular | 1200mm | 47W | Ra80+ | 4000K | Black | 100° | 4865 lm | 104 lm/W | AC220-240V | |
| - | Regular | 1800mm | 70W | Ra80+ | 4000K | White | 100° | 8050 lm | 115 lm/W | AC220-240V | |
| - | Regular | 1800mm | 70W | Ra80+ | 4000K | Black | 100° | 7245 lm | 104 lm/W | AC220-240V | |
| - | Regular | 2400mm | 90W | Ra80+ | 4000K | White | 100° | 10350 lm | 115 lm/W | AC220-240V | |
| - | Regular | 2400mm | 90W | Ra80+ | 4000K | Black | 100° | 9315 lm | 104 lm/W | AC220-240V | |
| - | Regular | 1200mm | 47W | Ra90+ | 4000K | White | 100° | 4648 lm | 99 lm/W | AC220-240V | |
| - | Regular | 1200mm | 47W | Ra90+ | 4000K | Black | 100° | 4183 lm | 89 lm/W | AC220-240V | |
| - | Regular | 1800mm | 70W | Ra90+ | 4000K | White | 100° | 6923 lm | 99 lm/W | AC220-240V | |
| - | Regular | 1800mm | 70W | Ra90+ | 4000K | Black | 100° | 6231 lm | 89 lm/W | AC220-240V |
- 1
- 2
- 3
- 4
- 5
- 6
- 20
| Name | Version | Dimension | System Power | CRI | CCT | Finish Colors | Beam Angle | System Output | Luminous Efficacy | Input Voltage | Download |
|---|---|---|---|---|---|---|---|---|---|---|---|
| - | Regular | 1200mm | 22W | Ra80+ | 4000K | White | 90° | 2090 lm | 95 lm/W | AC220-240V | |
| - | Regular | 1200mm | 22W | Ra80+ | 4000K | Black | 90° | 1881 lm | 86 lm/W | AC220-240V | |
| - | Regular | 1800mm | 33W | Ra80+ | 4000K | White | 90° | 3135 lm | 95 lm/W | AC220-240V | |
| - | Regular | 1800mm | 33W | Ra80+ | 4000K | Black | 90° | 2821 lm | 85 lm/W | AC220-240V | |
| - | Regular | 1200mm | 22W | Ra90+ | 4000K | White | 90° | 1797 lm | 82 lm/W | AC220-240V | |
| - | Regular | 1200mm | 22W | Ra90+ | 4000K | Black | 90° | 1617 lm | 74 lm/W | AC220-240V | |
| - | Regular | 1800mm | 33W | Ra90+ | 4000K | White | 90° | 2696 lm | 82 lm/W | AC220-240V | |
| - | Regular | 1800mm | 33W | Ra90+ | 4000K | Black | 90° | 2426 lm | 74 lm/W | AC220-240V | |
| - | High-Efficiency | 1200mm | 22W | Ra80+ | 4000K | White | 90° | 2640 lm | 120 lm/W | AC220-240V | |
| - | High-Efficiency | 1200mm | 22W | Ra80+ | 4000K | Black | 90° | 2376 lm | 108 lm/W | AC220-240V |
- 1
- 2
- 3
- 4
- 5
- 6
- 12
| Name | Version | Dimension | System Power | CRI | CCT | Finish Colors | Beam Angle | System Output | Luminous Efficacy | Input Voltage | Download |
|---|---|---|---|---|---|---|---|---|---|---|---|
| - | Regular | 1200mm | 22W | Ra80+ | 4000K | White | 90° | 2200 lm | 100 lm/W | AC220-240V | |
| - | Regular | 1200mm | 22W | Ra80+ | 4000K | Black | 90° | 1980 lm | 90 lm/W | AC220-240V | |
| - | Regular | 1800mm | 33W | Ra80+ | 4000K | White | 90° | 3300 lm | 100 lm/W | AC220-240V | |
| - | Regular | 1800mm | 33W | Ra80+ | 4000K | Black | 90° | 2970 lm | 90 lm/W | AC220-240V | |
| - | Regular | 1200mm | 22W | Ra90+ | 4000K | White | 90° | 1892 lm | 86 lm/W | AC220-240V | |
| - | Regular | 1200mm | 22W | Ra90+ | 4000K | Black | 90° | 1702 lm | 77 lm/W | AC220-240V | |
| - | Regular | 1800mm | 33W | Ra90+ | 4000K | White | 90° | 2838 lm | 86 lm/W | AC220-240V | |
| - | Regular | 1800mm | 33W | Ra90+ | 4000K | Black | 90° | 2554 lm | 77 lm/W | AC220-240V | |
| - | High-Efficiency | 1200mm | 22W | Ra80+ | 4000K | White | 90° | 2750 lm | 125 lm/W | AC220-240V | |
| - | High-Efficiency | 1200mm | 22W | Ra80+ | 4000K | Black | 90° | 2475 lm | 112 lm/W | AC220-240V |
- 1
- 2
- 3
- 4
- 5
- 6
- 12
| Name | Version | Dimension | System Power | CRI | CCT | Finish Colors | Beam Angle | System Output | Luminous Efficacy | Input Voltage | Download |
|---|---|---|---|---|---|---|---|---|---|---|---|
| - | Regular | 1200mm | 28W | Ra80+ | 4000K | White | 90° | 3080 lm | 110 lm/W | AC220-240V | |
| - | Regular | 1200mm | 28W | Ra80+ | 4000K | Black | 90° | 2772 lm | 99 lm/W | AC220-240V | |
| - | Regular | 1800mm | 42W | Ra80+ | 4000K | White | 90° | 4620 lm | 110 lm/W | AC220-240V | |
| - | Regular | 1800mm | 42W | Ra80+ | 4000K | Black | 90° | 4158 lm | 99 lm/W | AC220-240V | |
| - | Regular | 1200mm | 28W | Ra90+ | 4000K | White | 90° | 2648 lm | 95 lm/W | AC220-240V | |
| - | Regular | 1200mm | 28W | Ra90+ | 4000K | Black | 90° | 2383 lm | 85 lm/W | AC220-240V | |
| - | Regular | 1800mm | 42W | Ra90+ | 4000K | White | 90° | 3973 lm | 95 lm/W | AC220-240V | |
| - | Regular | 1800mm | 42W | Ra90+ | 4000K | Black | 90° | 3575 lm | 85 lm/W | AC220-240V | |
| - | High-Efficiency | 1200mm | 28W | Ra80+ | 4000K | White | 90° | 3780 lm | 135 lm/W | AC220-240V | |
| - | High-Efficiency | 1200mm | 28W | Ra80+ | 4000K | Black | 90° | 3402 lm | 122 lm/W | AC220-240V |
- 1
- 2
- 3
- 4
- 5
- 6
- 12
| Name | Version | Dimension | System Power | CRI | CCT | Finish Colors | Beam Angle | System Output | Luminous Efficacy | Input Voltage | Download |
|---|---|---|---|---|---|---|---|---|---|---|---|
| - | Regular | 300*300*70mm | 13W | Ra80+ | 2700K | White | 90° | 1683 lm | 129 lm/W | AC220-240V | |
| - | Regular | 300*300*70mm | 13W | Ra80+ | 3000K | White | 90° | 1782 lm | 137 lm/W | AC220-240V | |
| - | Regular | 300*300*70mm | 13W | Ra80+ | 4000K | White | 90° | 1980 lm | 152 lm/W | AC220-240V | |
| - | Regular | 300*300*70mm | 13W | Ra80+ | 6500K | White | 90° | 1980 lm | 152 lm/W | AC220-240V | |
| - | Regular | 300*300*70mm | 13W | Ra90+ | 2700K | White | 90° | 1445 lm | 111 lm/W | AC220-240V | |
| - | Regular | 300*300*70mm | 13W | Ra90+ | 3000K | White | 90° | 1544 lm | 119 lm/W | AC220-240V | |
| - | Regular | 300*300*70mm | 13W | Ra90+ | 4000K | White | 90° | 1703 lm | 131 lm/W | AC220-240V | |
| - | Regular | 300*300*70mm | 13W | Ra90+ | 6500K | White | 90° | 1703 lm | 131 lm/W | AC220-240V | |
| - | High-Efficiency | 300*300*70mm | 13W | Ra80+ | 2700K | White | 90° | 2223 lm | 171 lm/W | AC220-240V | |
| - | High-Efficiency | 300*300*70mm | 13W | Ra80+ | 3000K | White | 90° | 2340 lm | 180 lm/W | AC220-240V |
- 1
- 2
- 3
- 4
| Name | Version | Dimension | System Power | CRI | CCT | Finish Colors | Beam Angle | System Output | Luminous Efficacy | Input Voltage | Download |
|---|---|---|---|---|---|---|---|---|---|---|---|
| - | Regular | 300*300*70mm | 25W | Ra80+ | 2700K | White | 100° | 1339 lm | 54 lm/W | AC220-240V | |
| - | Regular | 300*300*70mm | 25W | Ra80+ | 3000K | White | 100° | 1418 lm | 57 lm/W | AC220-240V | |
| - | Regular | 300*300*70mm | 25W | Ra80+ | 4000K | White | 100° | 1575 lm | 63 lm/W | AC220-240V | |
| - | Regular | 300*300*70mm | 25W | Ra80+ | 6500K | White | 100° | 1575 lm | 63 lm/W | AC220-240V | |
| - | Regular | 300*300*70mm | 25W | Ra90+ | 2700K | White | 100° | 1150 lm | 46 lm/W | AC220-240V | |
| - | Regular | 300*300*70mm | 25W | Ra90+ | 3000K | White | 100° | 1229 lm | 49 lm/W | AC220-240V | |
| - | Regular | 300*300*70mm | 25W | Ra90+ | 4000K | White | 100° | 1355 lm | 54 lm/W | AC220-240V | |
| - | Regular | 300*300*70mm | 25W | Ra90+ | 6500K | White | 100° | 1355 lm | 54 lm/W | AC220-240V | |
| - | High-Efficiency | 300*300*70mm | 18W | Ra80+ | 2700K | White | 100° | 1781 lm | 99 lm/W | AC220-240V | |
| - | High-Efficiency | 300*300*70mm | 18W | Ra80+ | 3000K | White | 100° | 1875 lm | 104 lm/W | AC220-240V |
- 1
- 2
- 3
- 4
| Name | Version | Dimension | System Power | CRI | CCT | Finish Colors | Beam Angle | System Output | Luminous Efficacy | Input Voltage | Download |
|---|---|---|---|---|---|---|---|---|---|---|---|
| - | Regular | 300*300*65mm | 13W | Ra80+ | 2700K | White | 90° | 1216 lm | 94 lm/W | AC220-240V | |
| - | Regular | 300*300*65mm | 13W | Ra80+ | 3000K | White | 90° | 1287 lm | 99 lm/W | AC220-240V | |
| - | Regular | 300*300*65mm | 13W | Ra80+ | 4000K | White | 90° | 1430 lm | 110 lm/W | AC220-240V | |
| - | Regular | 300*300*65mm | 13W | Ra80+ | 6500K | White | 90° | 1430 lm | 110 lm/W | AC220-240V | |
| - | Regular | 300*300*65mm | 13W | Ra90+ | 2700K | White | 90° | 1044 lm | 80 lm/W | AC220-240V | |
| - | Regular | 300*300*65mm | 13W | Ra90+ | 3000K | White | 90° | 1115 lm | 86 lm/W | AC220-240V | |
| - | Regular | 300*300*65mm | 13W | Ra90+ | 4000K | White | 90° | 1230 lm | 95 lm/W | AC220-240V | |
| - | Regular | 300*300*65mm | 13W | Ra90+ | 6500K | White | 90° | 1230 lm | 95 lm/W | AC220-240V | |
| - | High-Efficiency | 300*300*65mm | 13W | Ra80+ | 2700K | White | 90° | 1667 lm | 128 lm/W | AC220-240V | |
| - | High-Efficiency | 300*300*65mm | 13W | Ra80+ | 3000K | White | 90° | 1755 lm | 135 lm/W | AC220-240V |
- 1
- 2
- 3
- 4
| Name | Version | Dimension | System Power | CRI | CCT | Finish Colors | Beam Angle | System Output | Luminous Efficacy | Input Voltage | Download |
|---|---|---|---|---|---|---|---|---|---|---|---|
| - | Regular | 300*300*65mm | 18W | Ra80+ | 2700K | White | 100° | 1105 lm | 61 lm/W | AC220-240V | |
| - | Regular | 300*300*65mm | 18W | Ra80+ | 3000K | White | 100° | 1170 lm | 65 lm/W | AC220-240V | |
| - | Regular | 300*300*65mm | 18W | Ra80+ | 4000K | White | 100° | 1300 lm | 72 lm/W | AC220-240V | |
| - | Regular | 300*300*65mm | 18W | Ra80+ | 6500K | White | 100° | 1300 lm | 72 lm/W | AC220-240V | |
| - | Regular | 300*300*65mm | 18W | Ra90+ | 2700K | White | 100° | 949 lm | 53 lm/W | AC220-240V | |
| - | Regular | 300*300*65mm | 18W | Ra90+ | 3000K | White | 100° | 1014 lm | 56 lm/W | AC220-240V | |
| - | Regular | 300*300*65mm | 18W | Ra90+ | 4000K | White | 100° | 1118 lm | 62 lm/W | AC220-240V | |
| - | Regular | 300*300*65mm | 18W | Ra90+ | 6500K | White | 100° | 1118 lm | 62 lm/W | AC220-240V | |
| - | High-Efficiency | 300*300*65mm | 13W | Ra80+ | 2700K | White | 100° | 1544 lm | 119 lm/W | AC220-240V | |
| - | High-Efficiency | 300*300*65mm | 13W | Ra80+ | 3000K | White | 100° | 1625 lm | 125 lm/W | AC220-240V |
- 1
- 2
- 3
- 4
| Name | Version | Dimension | System Power | CRI | CCT | Finish Colors | Beam Angle | System Output | Luminous Efficacy | Input Voltage | Download |
|---|---|---|---|---|---|---|---|---|---|---|---|
| - | Regular | 300*300*60mm | 13W | Ra80+ | 2700K | White | 90° | 1050 lm | 81 lm/W | AC220-240V | |
| - | Regular | 300*300*60mm | 13W | Ra80+ | 3000K | White | 90° | 1112 lm | 86 lm/W | AC220-240V | |
| - | Regular | 300*300*60mm | 13W | Ra80+ | 4000K | White | 90° | 1235 lm | 95 lm/W | AC220-240V | |
| - | Regular | 300*300*60mm | 13W | Ra80+ | 6500K | White | 90° | 1235 lm | 95 lm/W | AC220-240V | |
| - | Regular | 300*300*60mm | 13W | Ra90+ | 2700K | White | 90° | 902 lm | 69 lm/W | AC220-240V | |
| - | Regular | 300*300*60mm | 13W | Ra90+ | 3000K | White | 90° | 963 lm | 74 lm/W | AC220-240V | |
| - | Regular | 300*300*60mm | 13W | Ra90+ | 4000K | White | 90° | 1062 lm | 82 lm/W | AC220-240V | |
| - | Regular | 300*300*60mm | 13W | Ra90+ | 6500K | White | 90° | 1062 lm | 82 lm/W | AC220-240V | |
| - | High-Efficiency | 300*300*60mm | 13W | Ra80+ | 2700K | White | 90° | 1482 lm | 114 lm/W | AC220-240V | |
| - | High-Efficiency | 300*300*60mm | 13W | Ra80+ | 3000K | White | 90° | 1560 lm | 120 lm/W | AC220-240V |
- 1
- 2
- 3
- 4
| Name | Version | Dimension | System Power | CRI | CCT | Finish Colors | Beam Angle | System Output | Luminous Efficacy | Input Voltage | Download |
|---|---|---|---|---|---|---|---|---|---|---|---|
| - | Regular | 300*300*60mm | 16W | Ra80+ | 2700K | White | 100° | 1496 lm | 94 lm/W | AC220-240V | |
| - | Regular | 300*300*60mm | 16W | Ra80+ | 3000K | White | 100° | 1584 lm | 99 lm/W | AC220-240V | |
| - | Regular | 300*300*60mm | 16W | Ra80+ | 4000K | White | 100° | 1760 lm | 110 lm/W | AC220-240V | |
| - | Regular | 300*300*60mm | 16W | Ra80+ | 6500K | White | 100° | 1760 lm | 110 lm/W | AC220-240V | |
| - | Regular | 300*300*60mm | 16W | Ra90+ | 2700K | White | 100° | 1285 lm | 80 lm/W | AC220-240V | |
| - | Regular | 300*300*60mm | 16W | Ra90+ | 3000K | White | 100° | 1373 lm | 86 lm/W | AC220-240V | |
| - | Regular | 300*300*60mm | 16W | Ra90+ | 4000K | White | 100° | 1514 lm | 95 lm/W | AC220-240V | |
| - | Regular | 300*300*60mm | 16W | Ra90+ | 6500K | White | 100° | 1514 lm | 95 lm/W | AC220-240V | |
| - | High-Efficiency | 300*300*60mm | 13W | Ra80+ | 2700K | White | 100° | 1729 lm | 133 lm/W | AC220-240V | |
| - | High-Efficiency | 300*300*60mm | 13W | Ra80+ | 3000K | White | 100° | 1820 lm | 140 lm/W | AC220-240V |
- 1
- 2
- 3
- 4
